UNI-T UT39A+ Digital Multimeter AC DC Resistance Frequency Auto Range Meter. UT39+ series modern digital multimeters are portable devices designed for the electrical industry. They feature overvoltage, overcurrent alarms, and high voltage protection triggered during faulty operation. UT39C+ is suitable for HVACR maintenance with its temperature measurement feature. Designed according to CAT II 1000V/CAT III 600V safety standards.

Specifications:

• Model: UT39A+
• DC voltage (V): 400mV/4V/40V/400V/1000V; ±(0.5%+5)
• AC voltage (V): 4V/40V/400V/750V; ±(0.8%+3)
• DC current (A): 40uA/400uA/4mA/40mA/400mA/10A; ±(0.8%+3)
• AC current (A): 40mA/400mA/10A; ±(1%+2)
• Resistance (Ω): 400Ω/4000Ω/40kΩ/400kΩ/4MΩ/200MΩ; ±(0.8%+2)
• Capacitance (F): 4nF/40nf/400nF/4uF/40uF/400uF/4mF/10mF; ±(4%+5)

Features:

• Transistor hFE: √
• Diode: √
• Frequency response: 40Hz~400Hz
• Range selection: Manual
• Continuity test: √
• Data hold: √
• Backlight: √
• Low battery indication: √
• Auto power off: √
• Power: 1.5V battery (R03)×2
• Display: 56.5mm x 36mm
• Product net weight: 330g
• Product size: 175mm x 83mm x 53mm

Package Includes:

• 1 Pcs UNI-T UT39A+ Digital Multimeter AC DC Resistance Frequency Auto Range Meter
• 1 Pair Test Leads Probe
