Sanwa CD800A Digital Multimeter is an auto-ranging multimeter will tests AC and DC voltage and current as well as capacitance, resistance, and frequency. It features a large, easily readable display for use in the field. It has all of the basic functions that you expect from a good digital multimeter including continuity check (with buzzer), diode test, and data hold.

Features:

• 3-3 / 4 digits 4000 count
• 0.7% best accuracy
• Capacitance measurement (Not suitable for measurement of condensers with large leakage current)
• Frequency measurement (AC sine wave only)
• Data hold / Range hold
• Auto power off (30min.) (cancelable)
• AC frequency bandwidth: 40〜400Hz

Specification:

Function	Measuring Range	Resolution	Input Impedance
DC Volt	400m/4/40/400/600V	0.1mv	DC:10M-100MΩAC:10M-11MΩ
AC Volt	4/40/400/600V	0.001v
DC Ampere	40m/400mA	0.01mA
AC Ampere	40m/400mA	0.01mA
Resistance	400/4K/40K/400K/4M/40MΩ	0.1Ω
Capacitance	50n/500n/5μ/50μ/100μF	0.01nF
Frequency	5HZ-100KHZ
Duty Cycle	20%-80%
Continuity	Buzzer sounds at between 10Ω and120Ω. Open Voltage: Approx.0.4V
Diode Test	Open voltage: Approx. 1.5V
Bandwidth	40-400HZ (sine)
Size/Weight	H176*W104*D46mm/340g

Origin: Japan, Made in China. Introducing the Sanwa CD800a Digital Multimeter – your reliable and versatile tool for electrical testing and troubleshooting. Designed for professionals and DIY enthusiasts alike, the CD800a offers a wide range of features and functions to meet your diverse testing needs. With its durable construction and user-friendly design, this digital multimeter is ideal for use in various industries, including electrical engineering, automotive repair, HVAC, and more.

Key features of the Sanwa CD800a Digital Multimeter include:

1. High Accuracy Measurements: The CD800a offers high-precision measurements of voltage, current, resistance, capacitance, frequency, and temperature, ensuring accurate results for your testing requirements. 2. Large LCD Display: Equipped with a large backlit LCD, the CD800a provides clear and easy-to-read measurements, even in low-light conditions or cramped workspaces. 3. Auto-Ranging Function: The multimeter features an auto-ranging function, allowing it to automatically select the appropriate measurement range for the detected signal, saving you time and effort. 4. Safety Features: Designed with user safety in mind, the CD800a includes built-in overload protection and a non-contact voltage detection function, providing added peace of mind during testing. 5. Versatile Applications: Whether you’re testing electrical circuits, troubleshooting automotive systems, or measuring temperature in HVAC applications, the CD800a offers versatility and reliability for a wide range of testing tasks. 6. Portable and Convenient: With its compact and lightweight design, the CD800a is portable and easy to carry, making it suitable for on-the-go testing and fieldwork. 7. Long Battery Life: The multimeter is powered by standard AAA batteries, providing long-lasting performance for extended testing sessions. With its robust construction, advanced features, and user-friendly interface, the Sanwa CD800a Digital Multimeter is the perfect choice for professionals and hobbyists alike who demand accuracy, reliability, and versatility in their electrical testing equipment. Trust Sanwa for quality and precision in every measurement.
